PVC Powder Auto Feeding Dosing Weighing System For PVC Pipe Extrusion Line

PVC Powder Auto Feeding Dosing Weighing System For PVC Pipe Extrusion Line

Application and introduction

This system includes automatic feeding dosing mixing pneumatic conveying system, vacuum conveying system, etc. it is suitable for automatic dosing, mixing and conveying of all powder and chemical additives to plastic extruder. It has the advantages of high automation, no dust and high efficiency; Suitable for PVC wall panel, PVC pipes, Window profiles, SPC floor and other PVC industry customers.

The dosing system for PVC mixer
Our company design this PVC automatic mixing dosing conveying system which the computer can automatically control weighing and batching, and feeding to extruder.the complete PVC mixing system consists of:
1.Loading station(PVC loader+Caco3 loader+Recycle matterial).
2.Pneumatic vacuum conveying system.
3.PVC/Caco3/Recycle material storage silo.
4.Automatic raw material and additives dosing system for mixer.
5.PVC mixing unit or mixer.
6.Compound storage silo.
7.Automatic feeding system for extruder.

Powder scale weighing range	≤200 Kgs
Oil scale weighing range	1-50 Kgs
Powder weighing accuracy	Static≤±0.1% F.S, dynamic:±0.1--±0.5Kg.
Oil weighing accuracy	Static≤±0.1% F.S, dynamic:±0.1--±0.5Kg.
Conveying capacity	1-1500Kg/h
Transmission distance	Horizon≤80m; Vertical≤20m
Pipe diameter	DN50-100
Air source	Root's Blower
